Installation
22 RHDE250 ... 4000 (Contrac) 42/68-167-EN
M00103
1
2
3
4
L
45°
0.55
-0.0007
-0.0024
2.12
+0.0078
4.13 ... 4.72
Ø 0.87
0.91
0.83
3.62
1.10
4.13 ... 4.72
L - 9.01
3.90
2.76
1.10
0.20
0.98
13.50
1.02
0.67
3.15
1.97
+0.0015
0
2.36
5.91
7.87
9.84
2.48
1.89
1.61 (1.48) US)
Fig. 9: Dimensions in Inch
1 Cone 1 : 10
2 welding bushings are part of shipment
3 Connection pipe 1 1/2” DIN 2440 resp.1 1/2” schedule 80 pipe
size “L” acc. to requirements. The pipe is not included in
shipment.
4 Angular deflection of ball and socket joint:
Pointing towards the actuator: max. 3°
Pointing away from the actuator: max. 10°
Pos: 11.32 /==== === Seitenumbruch ======= = @ 0\mod_1126532365768_3101.d oc @ 3830
