ABB RVC User Manual

30
F-9 Phase error : closest value is 180°.
he controller could not find
a known configuration
Check connections,
capacitors and fuses
F-10 Phase error : closest value is 210°.
The controller could not find
a known configuration
Check connections,
capacitors and fuses
F-11 Phase error : closest value is 240°.
The controller could not find
a known configuration
Check connections,
capacitors and fuses
F-12 Phase error : closest value is 270°.
The controller could not find
a known configuration
Check connections,
capacitors and fuses
F-13 Phase error : closest value is 300°.
The controller could not find
a known configuration
Check connections,
capacitors and fuses
F-14 Phase error : closest value is 330°.
The controller could not find
a known configuration
Check connections,
capacitors and fuses
F-15 C/k not found after 10 trials.
The load is varying too quicly
Re-start the Autoset procedure under
more stable conditions.
F-16 C/k too small ( < 0.05).
Step size too small or CT ratio too big.
Adapt the step size or the CT ratio.
F-17 C/k too high ( > 1.00).
Step size too big or CT ratio too small
Adapt the step size or the CT ratio.
Message Description Recommended action

ABB RVC Specifications

General

Frequency	50/60 Hz
Temperature Range	-25°C to +55°C
Mounting	Panel Mounting
Manufacturer	ABB
Protection Class	IP20
Communication	Modbus RTU
Number of Steps	4, 6, 8, 12
