Figure 50. Optical ModuleBus Extension from CI810, CI820
ModuleBus Modem TB820
CI810 FCI
Base I/O Cluster
I/O Cluster 1
I/O Cluster 2
I/O Cluster 3
Optical ModuleBus
Port TB810
ModuleBus Modem TB820
Base I/O Cluster
I/O Cluster 1
I/O Cluster 2
I/O Cluster 3
Optical ModuleBus
Port TB810
CI820 FCI
TB815
Interconnection
Unit
TB 807
ModuleBus
Ter mi nat or
TB 806
ModuleBus
Cable Adaptor-In
I/O Station Configurations Section 2 Product Description
104 3BSE015969-600 A
