Section 2 Product Description I/O Station Configurations
3BSE015969-600 A 105
Figure 51. Optical ModuleBus Extension from CI840
CI840
Base I/O Cluster
I/O Cluster 1
I/O Cluster 2
I/O Cluster 3
TB806/TB846
TB842
TU846/TU847
ModuleBus
Modem
TB820
TB807
