Figure 57. Vertical Mounting of S800M I/O MTUs
796mm (31.3”)
84mm (3.3”)
58mm (2.3”)
20mm (0.8”)
162mm (6.37”)
84mm (3.3”)
120mm (4.72”)
1540mm (60.6”)
110mm (4.33”)
162mm (6.37”)
20mm (0.8”)
123mm (4.83”)*
* Measurement for TU847 and CI840
1579mm (62.2”)*
Mounting Section 2 Product Description
