Figure 58. I/O Station with Redundant CI820 FCIs
Cable adaptor, in
TB806
Terminator
TB807
TK801V0xx
CI820 FCI
TB815
Interconnection
Unit
Cable adaptor, out
TB805
162mm (6.36”)
174mm (6.84”)
Section 2 Product Description Mounting
3BSE015969-600 A 111
