Fieldbus Communication Interface Section 2 Product Description
36 3BSE015969-600 A
optional user text and item number are also provided. The communication plugs can
be inserted/removed without interrupting the communication between stations on
the bus.
The type designation CI810 in this document includes all types of models CI810,
CI810V1, CI810V2, CI810A and CI810B if no other information is given.
Table 2. Fieldbus Communication Interface
Module
Type
Description
CI801 Fieldbus Communication Interface for PROFIBUS-DPV1.
Support for Hot Configuration in Run and HART pass-through
(1)
.
PROFIBUS Modem for twisted pair cable.
Power supply 24 V (19.2 - 30 V d.c.) Rated insulation voltage 50 V.
(1) Always check the controller documentation for information about supported functionality.
CI810 Single Advant Fieldbus 100 FCI.
2 x Advant Fieldbus 100 Modems for twisted pair cable.
Power supply 24 V(19.2-30 V), Rated insulation voltage 50 V.
CI820/
CI820V1
Advant Fieldbus 100 FCI for redundancy configuration.
Advant Fieldbus 100 modem for twisted pair cable.
Power supply 24 V (19.2-30 V), Rated insulation voltage 50 V.
CI840/
CI840A
Fieldbus Communication Interface for PROFIBUS-DPV1 for
redundancy configuration.
Support for Hot Configuration in Run and HART pass-through
(1)
.
PROFIBUS Modem for twisted pair cable.
Power supply 24 V (19.2 - 30 V d.c.) Rated insulation voltage 50 V.
TB815 Interconnection unit used with CI820/CI820V1.
TU846 Module Termination Unit for dual CI840, redundant I/O.
TU847 Module Termination Unit for dual CI840, non-redundant I/O.
Also in a G3 compliant version (TU847Z).
