Section 2 Product Description I/O Modules
3BSE015969-600 A 51
AO820 Analog Output 4*1 channels, -20…20 mA, 0...20 mA,
4...20 mA, -10…10 V, 0...10 V, 2...10 V, 12 bit + sign, 
0.1%, individually isolated.
Current output RL maximum 550 Ohms.
Voltage output RL minimum 2 kohms.
Rated insulation voltage 50 V.
AO845/
AO845A
Analog Output 1*8 channels. 4...20 mA, 12 bit, 0,1%.
HART interface, RL maximum 750 Ohms.
Rated insulation voltage 50 V.
Advanced on-board diagnostics.
For single and redundant applications.
AO890 Analog Output 1*8 channels. 0…20 mA, 4...20 mA, 
12 bit, 0.1% I.S. interface, RL maximum 750 Ohms.
Rated insulation voltage 50 V
AO895 Analog Output 1*8 channels. 4...20 mA, 12 bit, 0.1%
I.S.and HART interface, RL maximum 750 Ohms.
Rated insulation voltage 50 V.
(1) Type L = S800L I/O
(2) Only to be used with AC 800M controller PM865 on ModuleBus.
Table 7. S800 Analog Modules (Continued)
Module
Type
Type
(1)
Description
