17
ABB
XT2 - XT4
ABB
*Per ulteriori informazioni vedere:
*For further details consult:
*Für weitere Informationen siehe: 1SDM000068R0001
*Pour plus d'informations voir:
*Para más información véase:
*有关更多信息请参考:
O 24-48VDC E LOCAL BUS
MODULE 110-240VAC/DC OR
TRAMITE MODULO 110-240VAC/DC
AUXILIARY SUPPLY THROUGH
Uaux.
V5
110-240VAC/DC
V4
+/L
-/N
24-48VDC
ALIMENTAZIONE AUSILIARIA
24-48VDC AND LOCAL BUS
Ekip Supply 24-48VDC
Ekip Supply 110-240VAC/DC
SUPPLY
K51
A)
*
*
I)
Ekip
80
K51
V1
K1
K2
K2
W3
W3
W4
W4
K1 K2
(B)(A)
(LOCAL BUS)
Q)
*
W2
W3 W4
XCT1
K1 K2 W3 W4
X8
JAA1
K1
