Switch Function Factory Checksum
number setting value
SGR3/1 When SGR3/1 = 1, the starting signal of stage I> is linked to TS1 0 1
SGR3/2 When SGR3/2 = 1, the tripping signal of stage I> is linked to TS1 0 2
SGR3/3 When SGR3/3 = 1, the starting signal of stage I>> is linked to TS1 0 4
SGR3/4 When SGR3/4 = 1, the tripping signal of stage I>> is linked to TS1 0 8
SGR3/5 When SGR3/5 = 1, the starting signal of stage I
o
> is linked to TS1 0 16
SGR3/6 When SGR3/6 = 1, the tripping signal of stage I
o
> is linked to TS1 0 32
SGR3/7 When SGR3/7 = 1, the starting signal of stage I
o
>> is linked to TS1 0 64
SGR3/8 When SGR3/8 = 1, the tripping signal of stage I
o
>> is linked to TS1 0 128
Checksum for factory setting of SGR3 0
