ABB TL Series User Manual

2/4
Safety warning
The device must always be protected on the incoming side by fuse or circuit
breaker with a max nominal current of 16A
1. Mounting Instruction TL1 + TLs (peripherical device)
Tightening torque
Important notice
After installation the cable coming out from the device must be fixed re-
liably.
2. Mounting Instruction TL1 Pole
Tightening torque

ABB TL Series Specifications

General

Rated Voltage	230/400 V AC
Mounting	DIN rail
Protection Degree	IP20
Product Type	Miniature Circuit Breaker (MCB)
Number of Poles	1, 2, 3, 4
Mechanical Life	20000 operations
Electrical Life	10000 cycles
Operating Temperature	-25°C to +55°C
