ABB TL Series User Manual

4/ 4
TL1
TL1 Pole
Max terminal cross section
mm2
6
Terminals
loss-proof screw
Screw Type
PZ1
Tightening torque: terminals
Nm
1.2
Tightening torque: screw sensor
Nm
1.2
Mounting
on DIN Rail
Pole/wall mounted
Switching status indication /brightness range
red/green LEDs
Max wiring length
m
100
Max wiring width
1000w
mm2
2,5
all other
mm2
1,5
sensor
mm2
0,75
Modules
n°
1
Reference standards
EN 60669-1
EN 60662-2-1
EN60730-1

ABB TL Series Specifications

General

Rated Voltage	230/400 V AC
Mounting	DIN rail
Protection Degree	IP20
Product Type	Miniature Circuit Breaker (MCB)
Number of Poles	1, 2, 3, 4
Mechanical Life	20000 operations
Electrical Life	10000 cycles
Operating Temperature	-25°C to +55°C
