INSTRUCTION HANDBOOK
71
Manually open the circuit breaker.
72
Manually close the circuit breaker.
73
By means of the allen key unscrew the 2 screws
located on the left side of the operating
mechanism.
74
By means of the flat screwdriver push the shaft
support as indicated by the arrow.
