9
Disassembly instruction tmaX Xt Xt7
16
By means the cross screwdriver, unscrew the
2 screws located in the bottom part of the
operating mechanism front cover fixing the
operating mechanism cover to the circuit
breaker main structure.
17
Manually lift the operating mechanism cover.
 
pr
otection (Plastic)
 
 
(Plas
tic)
 
 
 
(Plas
tic)
Disassembled parts
