3
2" x 40"
Mounting Pipe
Meter Run
"U" Mounting
Bolt
Saddle
Figure 1 (Saddle Mount)
Flat and lock washers
2 " Mounting Pipe
U - Bolt
with 9/16" bolt
Figure 3 (Typical Manifold Mount)
Figure 2 (Pipe Mount)
