Step 10:
u Now tighten all TE and CE foot screws with the tightening torque in sequence (1, 2, 3, 4, 5,
6, 7, 8).
Table: Tightening torque sequence
Gas outlet branch position TPL67-C / TPL67VC32 / TPL71-C
NB000 (045 / 315) 1, 2, 3, 4, 5, 6, 7, 8
NB090 1, 6, 3, 5, 8, 7
NB270 2, 5, 4, 6, 7, 8
Table13
Table: Tightening torque
Product Thread size [mm] Tightening torque [Nm]
TPL67-C M 24 800
TPL67VC32 M 24 800
TPL71-C M 24 800
Table14
--------------------------------------------------------------------------------------------------
