Operation Manual / TPL65-A32 / -A33 / -A36 + TPL69-A32 / -A33
9 Taking out of operation at short notice / 9.2 Locking the rotor
© Copyright 2020 . All rights reserved. HZTL2498_EN Rev.F December 2020
u As specified in following Table of tightening torques, tighten inter-
mediate ring, assembly-disassembly device (90020) and locking
flange (94003) using screws (94006).
u Tighten nuts (74027) complete with washers (72018) on compressor
casing as specified in following Table of tightening torques.
Table of tightening
torques
Part number TPL69-A32 / -A33
72027 M16
105Nm
94006 M6
10Nm
94007 M6
10Nm
CAUTION
Make sure all components are clean and free from grease.
Page 102 / 123
