12 Spare parts
12.1 Ordering spare parts
When making inquiries or ordering spare parts, the following data must
be specified:
¡ Turbocharger type
¡ Serial number (HT……)
¡ Designation and part number.
Spare parts can be ordered from an official ABB Turbocharging service
station.
u If different design versions have not been taken into consideration in
this document, please contact an ABB Turbocharging service station.
CAUTION
Storage of spare parts
All spare parts ordered with the turbocharger must be kept complete
and ready for use.
u Parts showing signs of rust should be carefully cleaned and greased.
u Dispose of replaced and unusable parts in a professional and environ-
mentally compatible way.
Required customer spare part set (97070)
TPL65-A32 / -A33 / -A36
Quantity Description Part number
1 O-ring 42012
1 Gasket 42041
2 Gasket 42045
2 Verbus Ripp® washer 42058
2 Hexagon-head screw 42059
3 Hexagon nut 61037
12 Hexagon-head screw 61056
12 Verbus Ripp® washer 61057
3 Verbus Ripp® washer 61058
3 Hexagon-head screw 61059
1 Gasket 77005
1 O-ring (speed sensor) 86506
