Operation Manual / TPL65-A32 / -A33 / -A36 + TPL69-A32 / -A33
12 Spare parts / 12.1 Ordering spare parts
© Copyright 2020 . All rights reserved. HZTL2498_EN Rev.F December 2020
TPL69-A32 / -A33
Quantity Description Part number
1 O-ring 42012
1 Gasket 42041
2 Gasket 42045
15 Verbus Ripp® washer 42058 / 42063 / 61043 / 61057 /
61058
15 Hexagon-head screw 42059 / 42064 / 61044 / 61056 /
61059
3 Hexagon nut 61037
1 Gasket 77005
1 O-ring (speed sensor) 86506
Spare part set (97078) for turbine cleaning system (if provided)
CAUTION
Leaks
Improper assembly of the cleaning pipe and the nozzles can lead to
leaks and failure of the turbine cleaning system.
u Have work on the turbine cleaning system carried out by an ABB Tur-
bocharging Service Station.
Quantity Description Part number
2 Locking plate 51255
3 Nozzle 52208
6 Sleeve 52212
1 Locking plate 52213
6 Strain bolt 52217
6 Nut 52218
