Operation Manual / TPL65-A32 / -A33 / -A36 + TPL69-A32 / -A33
12 Spare parts / 12.4 View of cartridge group with part numbers
TPL65-A
© Copyright 2020 . All rights reserved. HZTL2498_EN Rev.F December 2020
Part number Designation
21000 Shaft
25000 Compressor wheel
32001 (in customer spare part set) Thrust bearing
32101 (in customer spare part set) Radial bearing at compressor end
32102 (in customer spare part set) Radial bearing at turbine end
32104 (in customer spare part set) Auxiliary bearing
32105 (in customer spare part set) Floating disc
32106 (in customer spare part set) Axial bearing
32107 Bearing bush
42001 Bearing casing
42002 Hood
42011 (in customer spare part set) O-ring
42012 (in customer spare part set) O-ring
42015 Sealing cover
42041 (in customer spare part set) Gasket
42045 (in customer spare part set) Gasket
42058 (in customer spare part set) Verbus Ripp® washer
42059 (in customer spare part set) Hexagon-head screw
42063 Verbus Ripp® washer
42064 Hexagon-head screw
43001 Partition wall
43005 (in customer spare part set) O-ring
43006 (in customer spare part set) O-ring
43007 (in customer spare part set) O-ring
86505 Speed sensor
86506 (in customer spare part set) O-ring
Page 121 / 123
