Operation Manual / TPL65-A32 / -A33 / -A36 + TPL69-A32 / -A33
8 Disassembly and assembly / 8.8 Dismantling and fitting nozzle ring
at turbine end
© Copyright 2020 . All rights reserved. HZTL2498_EN Rev.F December 2020
u Pull gas inlet casing complete with nozzle ring just far enough away
from gas outlet casing that nozzle ring (56001) can be lifted away.
u Loosen the hexagon nuts (90178) on the studs.
u Fully withdraw the gas inlet casing and remove it.
CAUTION
When setting down the gas inlet casing to one side, use suitable under-
lays and take care not to damage the brackets of the insulation.
u Remove (optional) gasket (61050).
Nozzle ring assembly
If present:
u Insert (optional) gasket (61050) into slot in gas inlet casing (61001).
u Align gas inlet casing and secure using hexagon nuts (90178) on studs
(90177).
u Insert nozzle ring (56001) and position it.
u Brush screw threads (61044) with high temperature grease.
u Fit the gas inlet casing flange to the gas outlet casing using screws
(61044) and Verbus Ripp® washers (61043), then tighten it.
u Remove the hexagon nuts (90178) from the studs (90177).
u Replace the studs (90177) with hexagon-head screws (61044) and Ver-
bus Ripp® washers (61043).
u Remove lifting gear from gas inlet casing (51001).
u Attach the insulation to the gas inlet casing (51001).
