ABB TPL67-C Series

Operation Manual / TPL67-C.. - TPL71-C..
Disassembly and assembly
8
Module w
eights
8.2
Page 92
© Copyright 2017 ABB. All rights reserved.
February 2017 HZTL2488_EN Revision D
Complete compressor casing
TPL67-C
TPL71-C
240 360
NOTICE
The total weight of the complete compressor casing is an addition of the
weights of the compressor casing, the diffuser and the wall insert.
Weight [kg]
