30 Maintenance guide UCG | 1ZSE 5492-124 en, Rev 6
Fig. 19. Contact replacement, pulling out shaft.
Shaft 3Shaft 2
Contact
Shaft 1
Fig. 18. Contact replacement, taking away split pins.
Contact
Shaft 1
Washer with
larger diameter
