Introduction 1 – 10 Advant Controller AC 31 / Issued: 01.99
3
Products Description Order no.
90 series remote units
(with CS31 bus connection)
For 50 and 90 series basic units, not centrally extensible
07 DI 92 24V 24 V DC Digital remote unit
with 32 inputs,
24 V d.c. power supply
GJR 525 2400 R0101
07 DC 91 24 V DC Digital remote unit
with 16 inputs, 8 transistor outputs 24 V d.c./0.5 A
and 8 channels configurable for input/output
24 V d.c. power supply
GJR 525 1400 R0202
07 DC 92 24 V DC Digital remote unit
with 32 channels configurable for input/output,
transistor outputs 24 V d.c./0.5 A,
24 V d.c. power supply
GJR 525 2200 R0101
07 AI 91 24 V DC Analog remote unit
with 8 inputs configurable for current/voltage/ Pt 100/Pt 1000 or
thermocouple types J, K, S)
resolution 12 bits
24 V d.c. power supply
GJR 525 1600 R0202
07 AC 91 24 V DC Analog remote unit
16 channels configurable for input/output,:
1. 16 channels configurable in pairs for input/output, 8 bits,
current, voltage
2. 8 inputs and 8 outputs, 12 bits, current, voltage
GJR 525 2300 R0101
Remote units with IP 67
protection (with CS31 con-
nection)
For 50 and 90 series basic units, not centrally extensible
07 DI 93-I 24VDC Digital remote unit with IP 67 protection
with 16 inputs,
24 V d.c. power supply
GJV 307 5613 R0202
07 DO 93-I 24VDC Digital remote unit with IP 67 protection
with 8 outputs, 24 V d.c., 2 A transistor,
24 V d.c. power supply
GJV 307 5611 R0202
07 DK 93-I 24VDC Digital remote unit with IP 67 protection
with 8 inputs and 4 outputs, 24 V d.c., 2 A transistor,
24 V d.c. power supply
GJV 307 5623 R0202
Remote counter units
(with CS31 bus connection)
For 50 and 90 series basic units, not centrally extensible
High-speed remote counter unit, max. 50 kHz
4 inputs A/A, B/B, C/C – 5, 15 or 24 V d.c.
Modes : incremental, A-B (32 bits), A+B (32 bits), 3 (16 bits) stand-
alone counters or 3 (16 bits) frequency meters
100 ms to 6536.5 s
enable, reset, setpoint, reference point
7 transistor outputs (24 V d.c./0.5 A) for local comparison manage-
ment between 2 instructions and the counter content.
ICSF 08 D1 24VDC 24 V d.c. power supply FPR 332 3101 R1012
ICSF 08 D1 230VAC 230 V a.c. power supply FPR 332 3101 R0016
ECZ Plug-in base for mounting remote counter units FPR 370 0001 R0001
