5.8 Configuration messages
Common header
Data
Byte 0-4
Byte 5
Byte 6-10
Byte 11-15
Byte 16-20
Byte 21-25
Byte 26-30
Header
Tag=2
Parameter 0
Parameter 2
Parameter 2
Parameter 3
Parameter 4
Parameter x: Configuration parameter x, coded on 5 bytes as follow:
➢ First byte: Parameter identifier. Refer to the parameter identifier in the section Parameters
configuration
➢ Next 4 bytes: Parameter value. Unsigned 32 bits value in big endian format (MSB first).
5.9 Frame pending messages
Byte 0
Byte 1
Type=0
Acknowledge token
When additional messages are available on a gateway, this uplink message is sent to trigger the gateway
sending (if no other messages are pending).
Note:
1- To shorter the payload, this message is only 2 Bytes long (no common header).
