Abeeway Micro Tracker - Debug Command

Micro Tracker Reference Guide FW 1.7 V1.1
Page 35 of 39
11th october 2018
Restricted distribution
Parameter
ID
Unit
Range
Description
confirmed_ul_retry
(2)
0x13
none
0-8
The number of retries for each confirmed uplink when the
confirmation is not received
Note:
(1) Refer to the section Strategy used for more details
(2) Refer to the section Confirmed uplink for more details
6.6.5 BLE parameters
Parameter
ID
Unit
Range
Description
BLE_beacon_count
0x0F
none
1-4
Maximum number of BLE beacons to report
BLE_beacon_timeout
0x10
second
1-5
Timeout used by the BLE beacon for geolocation
6.6.6 Miscellaneous parameters
Parameter
ID
Unit
Range
Description
pw_stat_period
0x02
second
0, 300 - 604800
Period of the Energy status report.
When 0, no energy status report is transmitted.
Not used for micro trackers
config_flags
0x0D
none
Configuration flags:
bit 0: Frame pending mechanism
bit 1: Activate long button press to switch to off mode
bit 2: Double short press configuration: Alert (0) vs SOS (1)
bit 3: Send a configuration uplink message in response to
a configuration modification downlink. Used to confirm
the action.
bit 4: WIFI payload with Cypher (0) or without Cypher(1)
bit 5: Activate BLE advertising
Example:
To modify the heartbeat period to 1 hour, the command 0x0B020100000E10 should be sent.
Description:
➢ (0x0B): set the parameter
➢ (0x02): with an ack token of 2
➢ (0x01): heartbeat message period
➢ (0x 00 00 0E 10): to a value of 3600s = 1 hour
6.7 Debug command
Debug downlink commands allow to trigger specific behavior.
Byte 0
Byte 1
Byte 2
0xFF
ACK
Debug CMD ID
Debug CMD ID:
➢ 0x01 Reset the device
➢ 0x02 BLE bond remove
