Abeeway Micro Tracker - Page 34

Micro Tracker Reference Guide FW 1.7 V1.1
Page 34 of 39
11th october 2018
Restricted distribution
6.6.2 Parameters for side operation modes
Parameter
ID
Unit
Range
Description
periodic_pos_period
0x03
second
0, 900 - 604800
Period of the periodic position report.
A null value (0) disables this reporting.
geoloc_method
0x06
none
0-4
Oneshot geolocation policy used for alert,periodic or on
demand positions:
0- WIFI
1- GPS
2- LP-GPS (AGPS/GPS)
3- WIFI-GPS only (WIFI then GPS if WIFI fails in one
geolocation cycle)
4- WIFI-LPGPS only (WIFI then low power GPS if WIFI fails
in one geolocation cycle)
5- BLE scan only
6.6.3 Parameters for GPS and low power GPS geolocation modes
Parameter
ID
Unit
Range
Description
GPS
gps_timeout
0x09
second
30-300
Timeout for GPS scans before sending a GPS timeout
message.
gps_ehpe
0x0B
meter
0-100
Acceptable GPS horizontal error for GPS geolocation
gps_convergence
0x0C
second
0-300
Time let to the GPS module to refine the calculated
position
gps_standby_timeout
0x11
second
10-7200
Duration of the GPS standby mode before going OFF.
Low power GPS
agps_timeout
0x0A
second
30-250
Timeout for LPGPS scans before sending the timeout
message.
6.6.4 LoRa parameters
Parameter
ID
Unit
Range
Description
transmit_strat
(1)
0x0E
none
0-4
Transmit strategy in motion:
0 - Single fixed. Single TX. Use provisioned data rate.
1 - Single random: Single TX. Rate in [SF7..SF12].
2 - Dual random: First TX with rate in [SF7..SF8], next TX
with rate in [SF9..SF12].
3 - Dual fixed: First TX in [SF7..SF8]. Next Use provisioned
data rate. (not recommended)
4 – Network ADR. The LoRa network controls the number
of transmissions.
confirmed_ul_bitmap
(2)
0x12
none
0x0 – 0xFFFF
Bitmap enabling the LoRa confirmation of specific type of
uplink message
