6.2 Operational mode configuration
The operating mode can be remotely configured with a downlink LoRa message built as follow:
Byte 0
Byte 1
Byte 2
0x02
ACK
Mode
ACK: Acknowledge token. Refer to the section Acknowledge token.
Mode: operating modes. Acceptable values are:
➢ 0- Standby
➢ 1- Motion tracking
➢ 2- Permanent tracking
➢ 3- Motion start/end tracking
➢ 4- Activity tracking
➢ 5- Off mode
Example:
Changing the operating mode to “motion track” (01) with an ack token of 3: 0x020301.
6.3 Position on demand
Whatever the state, a position can be requested from the tracker using the message:
Byte 0
Byte 1
0x01
ACK
Example:
Position on demand message with ack token of 2: 0x0102.
The tracker will answer with a position message.
6.4 Request device configuration
Byte 0
Byte 1
Byte 2-21
0x03
ACK
Parameter ID list (optional)
Parameter ID list: List of requested parameters identifiers.
➢ Each single byte contains a single identifier.
➢ The list can have up to 20 parameters.
➢ Parameter IDs are the one used to configure the device (see section Parameters configuration ).
➢ Special parameters can be requested.
➢ The list can be empty. In this case, all parameters are requested.
Special parameter Id:
➢ 0xFD: get the BLE version.
➢ 0xFE: get the firmware version.
Notes
1- The tracker answers this request with a Configuration uplink message (section Configuration
messages).
2- The uplink contains a maximum of 5 parameters.
3- If the number of parameters is greater than 5, the tracker will send the needed number of uplinks to
fulfill the request.
