ABELL A-82 UHF Service Manual
第 1 页 共 41 页
Component List
Version: 01 A82(D04) A Side BOM
No. Specification Packing Description Qty Part No.
Chip Resistor
1 0R 0402 ±5% 7 R14 R27 R42 R52 R71 R68 R244
2 0.39R 1206 ±5% 3 R236 R237 R238
3 4.7R 0402 ±5% 2 R2 R8
4 10R 0402 ±5% 1 R1
5 100R 0402 ±5% 3 R46 R50 R449
6 220R 0402 ±5% 1 R18
7 330R 0402 ±5% 2 R5 R6
8 390R 0402 ±5% 1 R253
9 470R 0402 ±5% 1 R413
10 820R 0402 ±5% 1 R424
11 1K 0402 ±5% 14
CP6 CP7 CP15 C
P16 CP17 CP18 R11 R12
R49 R56 R72 R73 R74 R75
12 1.2K 0402 ±5% 1 R65
13 1.5K 0402 ±5% 1 R421
14 1.8K 0402 ±5% 1 R414
15 2K 0402 ±5% 1 R420
16 2.2K 0402 ±5% 3 R20 R45 R419
17 3.3K 0402 ±5% 2 R252 R402
18 4.7K 0402 ±5% 11
CP12 CP13 CP14 R21 R23 R44 R47 R51
R53 R443 R67
19 4.7K 0603 ±5% 1 CP11
20 5.6K 0402 ±5% 2 R247 R401
21 6.8K 0402 ±5% 1 R409
22 10K 0402 ±5% 5 R15 R16 R234 R417 R418
23 10K 0603 ±5% 1 R29
24 15K 0402 ±5% 3 R30 R411 R412
25 18K 0402 ±5% 2 R423 R468
26 22K 0402 ±5% 1 R400
27 33K 0402 ±5% 4 R404 R405 R407 R408
28 47K 0402 ±5% 6 R19 R31 R69 R135 R235 R415
29 51K 0402 ±5% 1 R410
30 56K 0402 ±5% 1 R43
31 100K 0402 ±5% 6 R17 R32 R41 R245 R328 R425
