ABELL A-82 UHF Service Manual
第 7 页 共 41 页
105 NC 0402 NC C210 C220 C298 C344 C346 R26
Adjustable
capacitor
106 6PF φ2 TZVY2Z060110T00 3 TC100 TC101 TC301
107 10PF φ2 TZVY2Z100A001R00 1 TC300
Tan-capacitor
108 0.1UF Type A ±20% 35V 2 C113 C114
109 1UF Type A ±20% 16V 1 C140
110 4.7UF Type R ±20% 6.3V 6 C133 C134 C138 C147 C152 C308
111 10UF Type R ±20% 6.3V 4 C357 C455 C425 C436
112 100UF Type B ±20% 6.3V 1 C1
Inductor
113
BLM18AG601SN1D
0603 Magnetic beads
600R
11
L98 L106 L110 L114 L117 L119 L212
L213 L300 L303 R416
114
BLM21PG300SN1D
0805
Magnetic beads
0805
CORE
3 L8 L208 L209
115
LQG18HN2N7S00
0603
HF, Multi
-
Layer inductor
1 L201
116
LQG15HN15NJ02
MLK1005S15NJ
0402
HF, Multi
-
Layer inductor
1 L210
117
LQG15HN18NJ02
MLK1005S18NJ
0402
HF, Multi
-
Layer inductor
2 L100 L211
118
LQG15HN22NJ02D
MLK1005S22NJ
0402
HF, Multi
-
Layer inductor
3 L105 L115 L306
119
LQW31HN27NJ03L
1206
HF, wire wound
inductor
1 L103
120
LQW31HN33NJ03L
1206
HF, wire wound
inductor
1 L109
121
LQG15HN47NJ02D
MLK1005S47NJ
0402
HF, Multi
-
Layer inductor
1 L116
122 LQG18H
N47NJ00D
0603
HF, Multi
-
Layer inductor
1 L113
123
LQG18HNR10J00D
0603
HF, Multi
-
Layer inductor
4 L101 L102 L107 L108
124 MLG1608SR22J 0603
HF, Multi
-
Layer inductor
5 L7 L10 L104 L111 L302
125 NLV25T-R22J-PF 2520
Normal, wire wound
inductor
1 L301
126 MLF1608DR47K 0603
LF, Multi-Layer
inductor
1 L4
127 MLF1608DR56K 0603
LF, Multi-Layer
inductor
1 L2
128 NLV25T-R56J-PF 2520
Normal, wire wound
inductor
1 L203
129 NLV25T-R68J-PF 2520
Normal, wire wound
inductor
1 L305
130 NLV25T-1R0J-PF 2520 Norma
l, wire wound
1 L200
