ABELL A-82 UHF Service Manual
第 13 页 共 41 页
Version：01 A82(D37)BOM Change based on （D04）
No. Material No. Packing Qty Part No.
Capacitance
1 1.5PF 0402 COG，±0.1PF，
16V
1
C220
2 2PF 0402 COG，±0.1PF，
16V
1 C318
3 2.4PF 0402 COG，±0.1PF，
16V
1 C334
4 3PF 0402 COG，±0.1PF，
16V
1 C105
5 3.6PF 0402 COG，±0.1PF，
16V
1 C342
6 9PF 0402 COG，±0.5PF，
16V
1 C349
7 27PF 0402 COG，±5%，16V 5 C328 C329 C333 C337 C339
8 56PF 0402 COG，±5%，16V 1 C118
9 NC 0402 1 C305
10 2PF 0603 COG，±0.1PF，
16V
2 TC300 TC301
11 3PF 0603 COG，±0.1PF，
16V
2 CY206 C218
12 5PF 0603 COG，±0.1PF，
16V
1 C216
13 330PF 0603 COG，±10%，16V 1 203
Inductance
14 2.2NH 0603
LQG18HN2N2SJ00
1 L201
15 23NH 1206
LQW31HN23NJ03L
1 L103
16 27NH 1206
LQW31HN27NJ03L
1 L109
17 0.4×φ1.6×3TR P Type
AIR-CORE COIL
with
Pin“E"
4 L204 L205 L206 L314
