ABEM WALKTEM 2 ABRIGDED USER MANUAL
WALKTEM vs TX-60 TRANSMITTER LOOP LEAD-IN CABLES
WALKTEM TX-60 STATUS LIGHTS
CONNECT ALL BATTERIES IN SERIES BEFORE
CONNECTING THE CABLE PLUG TO THE TX-60
It is critical to observe the correct polarities when
connecting batteries in series. A wrong connection can
result in equipment damage as well as personal injury.
Only attempt connection if you understand electrical
circuits, otherwise seek qualified assistance.
The standard lead-in wire for use with the original WalkTEM used “banana plug” connectors; the WalkTEM 2 and the TX-
60 use a heavier gauge wire, split-spade connectors and screw terminals:
Original
WalkTEM WalkTEM 2 & TX-60
Lead-in Lead-in Cable
Cable
