Mounting IR-1S Wrist transmitter
WARNING: The string lock is a safety feature to prevent strangling. Make sure that the ends
of the neck strap can be pulled out eg. if the transmitter gets caught on something. Never make
knots in the neck strap.
IR-1S Wrist transmitter can be used either with the enclosed wrist strap or hanging on a strap
around the neck.
Note! The neck strap is only included with the transmitter with a yellow function button.
Cleaning
Your IR-1S Wrist transmitter can be cleaned with a damp cotton wool pad with surgical spirit,
Chlorhexidine, or ethyl alcohol.
It can also be cleaned with a damp cloth (weak solution of washing up liquid). Wipe dry after
cleaning.
Operating environment
The IR-1S Wrist transmitter is designed for use indoors and outdoors but should be protected
against splashing liquid.
Technical data
Power consumption at rest:
Approx. 10 µA
Power consumption at transmitting:
Approx. 10 mA (GewaLink channel)
Battery life:
Approx. 1 year (30 seconds transmitting per day
with GewaLink channel)
Operating force button:
Approx. 170g
Range:
10-15m (GewaLink channels)
Measurements (L x W x H):
46 x 44 x 14 mm
Weight (incl. batteries):
25g
Operating temperature (excl. batteries):
-20
°
C to +45
°
C
Product life:
6 years
Accessories included with IR-1S Wrist transmitter
Art.no
Name
Description
Qty
890410
Neck strap
Allows IR-1S Wrist transmitter to be
carried around the neck
1 pcs
419300
Battery pack for Micro and Wrist
transmitters
Battery pack 1.5 V Silver oxide
1 pcs
