Introduction of BE6 Features 1-3
User’s Manual
5. Multi I/O Functions
!
2x Channels of Bus Master IDE Ports supporting up to four Ultra DMA 33/66 devices
!
2x Channels of Bus Master IDE Ports supporting up to four Ultra DMA 33 devices
!
PS/2 Keyboard and PS/2 Mouse Connectors
!
1x Floppy Port ( up to 2.88MB)
!
1x Parallel Port (EPP/ECP)
!
2x Serial Ports
!
2x USB Connectors
6. Miscellaneous
!
ATX form factor
!
One AGP slot, five PCI slots and two ISA slots
!
Supports PS/2 keyboard and PS/2 mouse wake-up functions
!
Built-in Wake on LAN header
!
Built-in IrDA TX/RX header
!
Built-in SB-Link
™
header
!
Built-in Wake On Ring header
!
Built-in SMBus header
!
Hardware monitoring
：
Included fan speed, voltages, CPU and system environment
temperature
!
One Thermal Sensor Cable included
!
Board size: 305 * 210mm
