Abit IL9 Pro - Default Chapter; Table of Contents

IL9 Pro/IL9 Pro-V iii
Contents
1. Hardware Setup ................................................ 1
1.1 Specifications .............................................................1
1.2 Choosing a Computer Chassis......................................2
1.3 Installing Motherboard................................................2
1.4 Checking Jumper Settings ...........................................3
1.4.1 CMOS Memory Clearing Header and Backup
Battery ......................................................................
3
1.5 Connecting Chassis Components .................................4
1.5.1 ATX Power Connectors .......................................4
1.5.2 Front Panel Switches and Indicators Headers.......5
1.5.3 FAN Power Connectors .......................................5
1.5.4 Chassis Speaker Connector.................................5
1.6 Installing Hardware ....................................................6
1.6.1 CPU Socket 775 .................................................6
1.6.2 DDR2 Memory Slots ...........................................8
1.6.3 PCI Express X16 Add-on Slots.............................9
1.7 Connecting Peripheral Devices.....................................9
1.7.1 Floppy and IDE Disk Drive Connectors.................9
1.7.2 Serial ATA Connectors ......................................10
1.7.3 Additional USB 2.0 Port Headers .......................10
1.7.4 Internal Audio Connectors ................................ 11
1.7.5 Front Panel Audio Connection Header ...............11
1.7.6 PCI and PCI Express X16, X1 Slots ....................12
1.8 Connecting Rear Panel I/O Devices............................ 12
2. BIOS Setup ...................................................... 13
3. Driver & Utility ................................................ 14
4. Appendix ......................................................... 15
4.1 規格（繁體中文）....................................................15
4.2 规格（简体中文）....................................................16
4.3 Troubleshooting (How to Get Technical Support?) ......17
4.3.1 Q & A..............................................................17
4.3.2 Technical Support Form....................................18
4.4 Contact Information..................................................19
