IL9 Pro/IL9 Pro-V 1
1. Hardware Setup
1.1 Specifications
CPU
• IL9 Pro: Support Intel Core 2 Duo, Pentium D, Pentium 4,
Celeron D Processor with 1066MHz FSB
• IL9 Pro-V:
Support Intel Core 2 Duo, Pentium Dual-Core,
Pentium D, Pentium 4, Celeron D Processor with 800MHz FSB
• Supports Intel Hyper-Threading Technology
Chipset
• IL9 Pro: Intel 945P / ICH7
• IL9 Pro-V: Intel 945PL / ICH7
Memory
• IL9 Pro: 4x 240-pin DIMM slots (DIMM1~DIMM4) support
maximum memory capacity up to 4GB
Supports Dual Channel DDR2 667 Un-buffered Non-ECC memory
• IL9 Pro-V: 2x 240-pin DIMM slots (DIMM1 and DIMM3) support
maximum memory capacity up to 2GB
Supports Dual Channel DDR2 533 Un-buffered Non-ECC memory
LAN
• Onboard 10/100/1000M LAN
Audio
• Onboard 7.1CH HD Audio CODEC
Serial ATA
• 4x SATA 3Gb/s
Expansion Slots
• 1x PCI-E X16
• 1x PCI-E X16 (PCI-E X4 bandwidth)
• 1x PCI-E X1
• 3x PCI
Internal I/O Connectors
• 1x Floppy port
• 1x ATA 100 IDE connector
• 4x SATA 3Gb/s connectors
• 2x USB 2.0 headers
• 1x FP-Audio header
• 1x CD-In connector
Rear Panel I/O
• 1x PS/2 Keyboard connector
• 1x PS/2 Mouse connector
• 1x COM port
• 1x LPT port
• 4x USB 2.0 connectors
• 1x RJ-45 Gigabit LAN connector
• 1x 7.1CH Audio Connector
• 1x S/PDIF Out
RoHS
• 100% Lead-free process and RoHS compliant
Miscellaneous
• ATX form factor (305mm x 244mm)
※
Specifications and information contained herein are subject
to change without notice.
※ The motherboard and its component layouts illustrated in
this chapter were based mainly on model “IL9 Pro”, unless
specifically stated.
