Installation and power supply connection
11
• Power drill or cordless drill (not included)
• Drill bit Ø 8 mm, appropriate for the wall material (not included)
• Pliers or cutter for breaking or cutting out the cable inlet in the rear part of the hous-
ing of the eMH1 (not included)
• Three flat-headed screws size M5 x 60, fully or partly threaded, with a head diam-
eter of 8.5 mm ± 1 mm (not included)
• Nylon wall plugs 8 x 40 mm suitable for the wall material (not included)
• Drilling template for the eMH1 model variants described in this manual (included)
• Spirit level if required (not included)
CAUTION!
Check the measurements on the drilling template with a calibrated mea-
suring tape BEFORE you mark the drill holes using the template and
then drill them
.
Drilling the mounting holes using the drilling template
Proceed as follows to drill the holes using the drilling template:
1. Place the drilling template vertically on the chosen mounting surface: Use a spirit
level if required.
2. Mark the drill holes using the template.
3. Drill the marked mounting holes (Ø 8 mm) and check the positions of the holes
using the drilling template.
4. Insert the wall plugs for the mounting screws.
Preparing the charging station
Proceed as follows to prepare the charging station for installation:
1. Open the cover shield of the EVSE 563 using the key supplied.
