Installation and power supply connection
13
DANGER!
Under all circumstances deactivate the miniature circuit breaker (MCB)
allocated to the eMH1 in your domestic power distribution box before
you begin electrical installation. Also ensure that the MCB cannot be
reactivated during installation. Otherwise there is a danger of electric
shock!
• In addition, please deactivate the upstream domestic residual current circuit break-
er (RCCB) to disconnect the internal electronics from the power supply terminal
block during installation. Further information available under “Specifications”, see
page 23.
• Insert the power supply cable through the lower cable inlet into the housing and fix
the cable using the internal strain relief clamp.
The supply cable for the 3 phase EVSE 563 is connected as follows:
Designation Wire colors Connection coding
Current-carrying conductor phase 1 BROWN
L1
Current-carrying conductor phase 2 BLACK
L2
Current-carrying conductor phase 3 GRAY
L3
Neutral BLUE
N
Protective earth GREEN-YELLOW
PE
DANGER!
The above color-coding is NOT internationally standardized: Should the
individual wires in the power supply cable be color-coded differently,
please immediately contact a qualified electrical contractor! Have the
power supply checked and replaced if necessary.
After successful connection to the power supply by a qualified specialist or electrical
contractor, please take the following steps to complete installation:
1. Replace the upper part of the housing.
2. Fix the upper part of the housing to the rear part using the appropriate screws.
3. Lock the cover shield of the EVSE 563 using the key supplied and store the key in
a safe place.
