ABL eMH1 WALLBOX - Sequence A: Wallbox Ready for Use

25
13. CHARGING
Before the charging procedure
During the charging procedure
After the charging procedure
1 Check that the LED indicators of
the Wallbox display this operat-
ing state. The vehicle may now
be connected
Error messages are also displayed
via the LEDs: p. 38
The green LED flashes every 5 seconds.
The blue LED is continuously Off
Sequence A
The Wallbox is ready for use
1sec 1sec 1sec 1sec 1sec 1sec
