Before the charging procedure
During the charging procedure
After the charging procedure
1 Check that the LED indicators
of the Wallbox display this
operating state. The charging
procedure will start automati-
cally as soon as the vehicle has
been recognised
2 p. 31
3 p. 32
The charging procedure will only
start when
• the vehicle has been connected
• the vehicle's charging timer is
activated
Sequence B1
The Wallbox is waiting for the vehicle to initiate the charging procedure
The green LED is continuously On
The blue LED is continuously Off
1sec 1sec 1sec 1sec 1sec 1sec
13. CHARGING
