ABL eMH1 WALLBOX - Sequence C2: Wallbox Charging Vehicle

31
Before the charging procedure
During the charging procedure
After the charging procedure
2 Check that the LED indicators of the Wallbox dis-
play this operating state. The charging procedure
will start automatically as soon as the vehicle has
been recognised
Sequence C2
The Wallbox is charging
The green LED is continuously Off
The blue LED is continuously On
1sec 1sec 1sec 1sec 1sec 1sec
13. CHARGING
