TECHNICAL DATA EL402, EL502 ENGLISH
Operating voltage: 12 - 24 V DC -10% / +15% STAB
Current: 12 V Max. 550 mA
Normal 240 mA
24 V Max. 270 mA
Normal 110 mA
Micro switch: max. 0.4 A 30 V AC / V DC resist. max. 10 W
Ambient temperature: -20° - +60°C
Bolt throw: 14,5 mm
Backsets: EL402: 25, 28, 30, 33, 35 mm (adjustable)
EL502: 50 mm
Forend: EL402: 25 mm
EL502: 22 mm
Trigger bolt: Symmetrical
Functions selected on
the lock case: Electrical function
- fail locked
- fail unlocked
Indications: Deadlocking status of double action bolt
Door clearance: 3 - 5 mm (Between forend and strike)
Connection cable: EA211 (6 m), EA221 (10 m) 9 x 0.14 mm2
Striker plates: EL402: EA307, EA308, 4613, 4614
EL502: LP721, LP731 (rebated)
LP711, LP714 (fl ush)
Not to be installed in doors with seal force.
Bolt and trigger bolt have to be lubricated during installation and when necessary.
Not suitable for use in fi re door.
STANDARDS
EN12209 Mechanical strength
!
!
!
