PROBOIL.2X user & installation guide v1e-2
25
2 PROBOIL.2X installer guide
2.1 About the PROBOIL.2X water heater:
2.1.1 Important technical data:
Boiler:
Measure:
Comments:
Model
PROBOIL.2X (AQ5001353)
Boiler type
Vented (unpressurised) displacement system
Unit dimensions
325x188x188mm, with connectors attached, without pipes attached
Overall weight
6.5 kg (Apx. when full)
Ambient operating
temperature
+5°C to +40°C (indoor use heated space only)
Minimum cold input pressure
Typically 1 bar (minimum usable), 1.5 bar (recommended). Varies by tap model,
values shown are assuming a minimum acceptable flow rate of 1 litre per minute.
Maximum cold input pressure
5.5 bar, if incoming cold water pressure is above this value than a pressure reducing
valve must be installed.
Boiling tank capacity
2.1 Litres +/- 5%
Typical usable volume
1.4 Litres, depending on temperature selection
Maximum Chlorine value for
incoming water
100mg/l
Tank material
Stainless steel (304)
Selectable in tank
temperatures
98° Maximum with adjustable heating point adjustment on screen
(75, 85, 90, 95, 96, 97- 98°C range)
Heat up time
From 20°C (full and cold tank) to 98°C displayed in Apx. 9 minutes
1 litre usage recovery, average time Apx. 11 minutes
2 litre usage recovery, approximate time Apx. 7 minutes (up to 60 UK cups per hour
dependant on usage pattern)
Thermal loss
Varies according to tap model, environmental and usage conditions, Apx. 4°C. loss
from tank to spout exit
Safety devices
- vented (unpressurised) tank
- minimum water level float switch to prevent dry heating
- digital thermal monitoring and control
- digital self-diagnostic control
- one shot dry burn 120°C thermal fuse (non-resettable)
- blow off connection for accidental blockage protection
Supply voltage range
AC 220-240V (50Hz)
Max. Power usage
(element on)
1.5kW at 240V AC
Power usage
Standby (screen off)
0.1-0.2W
Power usage
(keep warm at 98°C)
0.025kW, depending on ambient temperature, power on, no water usage.
Power usage
(reboil 1 litre at 98°C)
1.5kW (based on single 1 litre dispense of 98°C)
Power lead
1.4M (cable), 3 pin UK plug (13A), IEC connector, do not extend or replace.
