PROBOIL.2X user & installation guide v1e-2
2.2.2 Install the tap
Installation of the tap will vary from model to model, you must now refer to the separate installation guide
supplied with the tap or dispenser at this time.
1) Install the tap as per the model specific guidelines supplied with each tap connect the domestic cold (and hot if
applicable) water inputs to the tap.
2) Check you have the right hoses attached to the right inlets and outlets of the tap, you can quickly do this by very
slowly part opening the operating handle(s) to an on position and checking for output being out of the expected
hose into a bucket or similar.
⚠ if when you turn the 98°C handle on, water then comes out
of the high temperature inlet tap hose, the hoses are not
installed correctly, this must be corrected before continuing.
3) If you are installing a tap without a filtered cold water dispense option you should have 2 hoses without any
connection:
a. A outlet hose ending with a ¼” pushfit connection, this will be the cold water output to the filter
cartridge inlet and then onward to the boiler ¼” hose end.
b. A inlet hose with a 3/8” female threaded connection, this will be the taps hot water input from the
boiler output via a series of connections.
4) If you are installing a tap with a filtered cold water dispense option you should have 3 hoses without any
connection:
a. Two hoses ending with a ¼” pushfit connection, these will either be:
i. The filtered cold water input from the filter cartridge output to the tap.
ii. The filtered cold water output from the tap to the boiler.
It is important these two hoses with ¼” pushfit connections are not inverted, refer to the tap
instructions and double check and quickly mark which hose is which to avoid a later problem.
b. A inlet hose with a 3/8” female threaded connection, this will be the taps hot water input from the
boiler output via a series of connections.
