Absen AW Series - Page 18

Service hotline：400-700-3278
When installing the cabinets, you need to check whether the cabinets are flat, whether there is a
front-to-back misalignment between the cabinets, or if the cabinets are misaligned, and
whether the cabinets are squeezed.
Rear-installation, the rear-maintenance space of the screen should be reserved at 60cm-80cm.
2、Installation of the bottom connection hole
3、Pass the left and right connection holes of the box with screws and lock with nuts;
Nut on the right side of the box Screws on the left side of the box M8 * 30 screws and nuts
4、Install the second row of cabinets, and then screw the upper and lower cabinets;
5、Continue to install other cabinets;
