NX Series Product User Manual
For right-angle connectors, first embed the vertical bar, then the horizontal
bar, and tighten the machine screw;
3. The cabinet is fitted with pegs and hung on the horizontal bar.
4. Install the modules in sequence. Install the power cable and signal cable
accableing to the power supply and signal routing design scheme, and then
install the LED module after power-on inspection and confirmation.
3.3.2 Frame kit installation
3.3.2.1 The frame kit accessories are as follows:
Small cabinet (240*540mm)
frame kit
Suitable for 240*540 cabinet structure
Suitable for 240*1080 cabinet structure
Big cabinet (960*540mm)
frame kit
Suitable for 960*540 cabinet structure
M6 external hexagon self-tapping screws and
washers installation
Hang the cabinet on the frame with the
hanging pin
3.3.2.2 Installation steps:
1. According to the cabinet arrangement and the drawing of the frame, fix the
frame on the wall with M6 external hexagon self-tapping screws. During the
installation process, use a laser level and a spirit level to check and confirm
the flatness of the frame.
Note: There are 6 mounting holes for the big cabinet frame, 2 installation holes
for the small cabinet single frame, and 3 installation holes for the small cabinet
double frame.
