9. Technical data
Model number HDCC32500
Image sensor 1/3 inch progressive scan CMOS
Camera type Mini dome
Resolution 1080p25, 1080p30
Pixels (effective) 1920 (H) x 1080 (V)
Lens 2.8 mm, fixed lens
Horizontal angle of view 103.5°
Day/night switching Electromechanical IR cut filter
Minimum illumination (colour) 0.1 Lux
Minimum illumination (B/W) 0.01 Lux (image integration on)
Minimum illumination (IR) 0 Lux
Image integration 2x–16x
Noise reduction 2D DNR, 3D DNR
Electronic shutter control 1/25 s to 1/50,000 s
Camera control On-screen display (OSD) (only via ABUS HD-TVI DVR)
Backlight compensation WDR
Privacy masking 8 freely configurable masks
Digital zoom Yes
Video system HD-TVI
IR LEDs 24
IR range (up to) 20 m
Connections
Video signal (HD-TVI, BNC), video signal (FBAS, BNC, WDR off),
power supply (DC), 2-pin for WDR on/off
Power supply 12 V DC ± 10%
Power consumption Max. 340 mA (max. 4 W)
Operating temperature -20°C–+60°C
Humidity Max. 90%
Dimensions (H x)
59.1 x 89.6 mm
Weight 250 g
The effective IR range will depend on the installation location. If there are surfaces that absorb
light or no objects that reflect IR light in the field of view, the IR range will be reduced and/or the
video image will be too dark. Reflective objects in the immediate vicinity of the camera (e.g. roof
gutter or wall) may also result in the reflection of IR light, which can disturb the image.
With the HDCC31500 & HDCC32500 models, it is important to ensure that the IR LEDs are not
covered by the camera cap, as this could cause reflections.
