Abus HDCC81000 - System Info OSD Settings

35
SYS INFO SETTINGS
SOFT ADDRESS 1
SOFT ADDR ACT OFF
SOFT BAUD 2400
SOFT BAUD ACT OFF
BROADCAST ADDR ON
PELCO CHECKSUM ON
SYS TIME
BACK EXIT
Function Description
SOFT ADRESS (1-255): Dome ID for using control via the RS-485 protocol.
Alternatively, the ID can be set using DIP switches.
SOFT ADDR ACT OFF: Deactivation of the software dome ID
ON: Activation of the software dome ID
SOFT BAUD (2400-19200): Baud rate setting for the RS-485 interface.
Alternatively the baud rate can be set using DIP switches.
SOFT BAUD ACT OFF: Deactivation of the baud rate setting via OSD
ON: Activation of the baud rate setting via OSD
BROADCAST ADDR ON: If the control unit has the ID 0 all cameras connected to the
bus can be controlled.
OFF: Function deactivated
PELCO CHECKSUM Only applies if the Pelco D/P protocol is being used.
ON: Checksum test following each control command
OFF: Test deactivated
SYS TIME Settings for date and time
