3.7 Audio input & Audio output
Function Description Comments
Audio input „IN“ MIC / LINE Interface
LINE: 2-2.4Vss, 1KΩ
„GND Ground connector (common for input and output)
Audio output „OUT“ Impedance: 600 Ω
Frequency range: 20 Hz – 20 kHz
Output power: 20 mW @ 16Ω
