Technical data
• Power supply DC 3 V Lithium Battery (built-in)
• Smoke detection photoelectric reection
• Visual operating display LED ashes approx. every 6 minutes
• Electric consumption 9.8 μA (Ø standby) || 80 mA (Ø alarm)
• Operating temperature 0° to 45° C
• Air humidity 10 % to 90 % (non-condensing)
• Sound pressure > 85 dB (A)@3 m
• Alarm mute mode 9 minutes
• Detection range max. 40 m² within a single room
• Installation location ceiling (internal rooms only)
Functions and technical features
• The smoke alarm does not detect gases, vapours, heat and fire/flames!
• It is possible that people with limited hearing may not hear the alarm!
For such cases special alarms with optical signalling are available.
• Especially high electromagnetic radiation may affect unit operation.
Therefore, do not install the alarm near devices which emit electromagnetic
radiation or close to magnets.
• This smoke alarm works according to the principles of optics (photoelectric
reflection) and contains a measuring chamber in which penetrating smoke
particles are measured.
Technical data Functions and technical features
• If the alarm threshold is exceeded, a loud, audible alarm will sound.
• The alarm will switch itself off as soon as the measuring chamber becomes
smokefree again.
Emergency procedure when alarm sounds
(1) Alert all co-residents
(2) Offer assistance to children, disabled and elderly people and
invalids.
(3) Close all windows and doors behind you.
(4) Leave the building immediately.
(5) Do not use the elevators.
(6) Alert the fire service: tel. 112
Emergency procedure when alarm sounds
